Duplex with flatbed scanner


• 2 IN 1 scanner (Duplex and flatbed scanning in one machine)
• Scanning speed 25 ppm/ 50 ipm Tray capacity 50 sheets
• A3 scanning function
• Scan business card, credit card, ID Card, Cheque and A4


Features

Flatbed Scanner

- Duplex and flatbed scanning in one machine.
- Scan business card, credit card, ID Card, Cheque, A4 and plastic card.
duplex 2 in 1 scanner

- 25 ppm/ 50 ipm.
- User-friendly, just simply press you can scan documents to PDF, Searchable PDF, OCR.
- Tray capacity 50 sheets.

Software Bundled

Hotcard BizCard Finder
BizCard Finder , provides BCR Technology and Photo /Document database for information management. Through BizCard Finder, you can quickly and easily convert the vital contact information on business cards into a convenient, searchable, digital database that can be easily synchronized between PC, NoteBook, and PDA

ABBYY FineReader Sprint
Powerful document management software for OCR, PDF creation, or format conversion to Microsoft Word, Excel, Text, Html, Searchable PDF. Support Thai and other 183 languages.

DI Capture
Image capture and management software featured with indexed archives. It also makes it easy to import, export, edit, and organize documents and images in an efficient way.

Doc Action
Button utility is designed to specify your personalized scanning configuration settings which make documents scanning easily.

Specification
Image Sensor CCD Sensor x 3
Optical Resolution 600 dpi
Hardware Resolution Flatbed: 600 x 600 dpi
ADF: 600 x 600 dpi
ADF Capacity 1. 50 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs), Max. thickness under 5mm (0.2").
2. 20 sheets (Business cards)
Note: Maximum ADF capacity varies, depending upon paper weight.
Scanning Speed
( ADF )
8 ppm/ 8 ipm (Color mode, 200 dpi, A4 Portrait)
25 ppm/ 50 ipm (Grayscale mode, 200 dpi, A4 Portrait)
25 ppm/ 50 ipm (B&W mode, 200 dpi, A4 Portrait)
Note: Results may vary depending upon your scanning application, computer processor and system memory.
Scanning Area
(W x L)
Flatbed:
Max. 216 x 297 mm (8.5" x 11.69")
Min. 12.7 x 12.7 mm (0.5" x 0.5")
ADF:
Max. 216 x 356 mm (8.5" x 14")
Min. 13.2 x 13.2 mm (0.52" x 0.52")
Acceptable Paper Sizes
(W x L)
Flatbed:
Max. 216 x 297 mm (8.5” x 11.69”)
Min. 12.7 x 12.7 mm (0.5” x 0.5”)
ADF:
Max. 220 x 356 mm (8.66” x 14”)
Min. 90 x 114 mm (3.55” x 4.5”)
Acceptable Paper Weight
(Thickness)
50 to 105 g/㎡ (14 to 28 Lbs)
Action Button Scan, Up, Down
Power Supply 24 Vdc/ 0.75 A
Interface USB 2.0
Net Weight 4.5 Kgs (9.92 Lbs)
Dimensions
(W x D x H)
481 x 327 x 203 mm (18.93" x 12.87" x 7.98")
Protocol TWAIN Compliant
OS Windows 2000 / XP / Vista / 7 / 8
Hardware Requirements Pentium IV 2.0 GHz processor or faster CPU
CD-ROM Drive
One available USB Port
512 MB RAM or higher recommended
800 MB free HDD space (1 GB or larger recommended)
