| • Simplex Auto-Feed Document Scanner • Color scanning, 600 Dpi • Ho Speed 25 ppm • 50 Sheets ADF Capacity • Business Cards to Legal Sized Documents Scanning Available • Small Footprint • Scan to JPEG, BMP, PNG, TIFF, Multi-TIFF, PDF, Multi-PDF, Searchable PDF |
|
Features |
|
 |
• Auto-Feed scanning • Simplex scanning • Resolution 600 dpi Scan to • JPEG, BMP, PNG, TIFF, Multi-TIFF • PDF, Multi-PDF, Searchable PDF • OCR / Print / E-mail |
 |
Other functios |
| • Auto-size Scanning • Auto-Crop • Auto-Rotation • Blank page Deletion • Color Drop-Out |
|
| Software Bundled | |
Hotcard BizCard Finder |
You can quickly and easily convert the vital contact information on business cards into a convenient, searchable, digital database that can be easily synchronized between PC, NoteBook, and PDA. |
ABBYY FineReader Sprint |
High accuracy OCR software |
Doc Action |
provides a personalized operation system; you can easily set up your scanning way and use to have a simple processing way and time-save making your work smart and quick. |
| Specification | |
| Image Sensor | CIS |
| Light Source | LED |
| Resolution | 600 Dpi |
| Hardware Resolution | 600 x 600 Dpi |
| Scan Modes | - Color: Input 48-bit, Output 24-bit |
| - Grayscale: Input 16-bit, Output 8-bit | |
| - Black & White: 1-bit | |
| ADF Capacity | - 50 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs), |
| Maximum thickness under 5mm (0.2”). | |
| - 20 sheets (Business Card) | |
| Note: Maximum ADF capacity varies, depending upon paper weight. | |
| Scanning Speed ( ADF ) | - 25 ppm (Grayscale mode, 200 dpi, A4 Portrait) |
| - 25 ppm (B&W mode, 200 dpi, A4 Portrait) | |
| - 5 ppm (Color mode, 200 dpi, A4 Portrait) | |
| Scanning Area (W x L) | - Maximum: 216 x 356 mm (8.5” x 14”) |
| - Minimum: 13.2 x 13.2 mm (0.52” x 0.52”) | |
| Acceptable Paper Sizes | - Maximum: 220 x 356 mm (8.66” x 14”) |
| (W x L) | - Minimum: 50.8 x 50.8 mm (2” x 2”) |
| Acceptable Paper | - 50 to 105 g/㎡ (14 to 28 Lbs) |
| Weight (Thickness) | |
| Action Button | Scan, File, Custom (PDF) |
| Power Supply | 24 Vdc/ 0.75 A |
| Interface | USB 2.0 |
| Net Weight | 1.66 Kgs (3.66 Lbs) |
| Dimensions (W x D x H) | 263 x 127.5 x 148 mm (10.36” x 5.02” x 5.83”) |
| Protocol | TWAIN Compliant |
| OS | Windows XP / Vista / 7 / 8 / 10 |
| Hardware Requirements | - Pentium® IV 2.0 GHz processor |
| (Pentium IV 3.0 GHz processor recommended) | |
| - CD-ROM Driver One available USB Port (USB 2.0 recommended) - 1GB RAM or higher recommended - 800 MB free HDD space (1 GB or larger recommended) |
|
