High Speed Duplex Document Scanner

PS396 Duplex ADF Scanner

- Duplex document scanning.
- Color, Resoltion 600 Dpi.
- 30 ppm/ 60 ipm
- Support longer paper up to 200 inches
- Able to scan business card, ID card, credit card, Cheque, document up to A4.
- User-friendly
- Suitable for Government department, Academy, Factory, Business Office, etc.


Features


- Duplex document scanning.
- Color, 600 Dpi
- 30 ppm, 60 ipm
- Support longer paper up to 200 inches.

- Auto crop, Auto size scanning, Auto deskew, Remove blank page, Image edge fill etc.
- Tray capacity 100 sheets.
- Able to scan A4, business card, credit card, plastic card, ID card.
- With one touch button, any documents will be convert to image files such as JPEG, BMP, PNG, TIFF, Multi-TIFF, PDF, Searchable PDF, scan to email, printing and OCR in order to save as Word or Excel.
- Able to use with WAC OMR.

Software Bundled

ABBYY FineReader Sprint
Powerful document management software for OCR, PDF creation, or format conversion to Microsoft Word, Excel, Text, Html, Searchable PDF. Support Thai and other 170 languages.

Page Manager
Document management software

Doc Action
Button utility is designed to specify your personalized scanning configuration settings which make documents scanning easily.

Specification
Image Sensor CCD Sensor x 2
Light Source LED
Optical Resolution 600 dpi
Hardware Resolution 600 x 600 dpi
Scan mode Color: Input 48-bit,Output 24-bit
Grayscale: Input 16-bit,Output 8-bit
Black & White: 1-bit
ADF Capacity 1. 100 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs)
2. 30 sheets (Business Cards)
3. Plastic Card, Max. thickness under 1.2 mm.

Note: Maximum ADF capacity varies, depending upon paper weight.
Scanning Speed
( ADF ) .
30 ppm/ 60 ipm (Grayscale mode, 200 dpi, A4 Portrait)
30 ppm/ 60 ipm (B&W mode, 200 dpi, A4 Portrait)
20 ppm/ 40 ipm (Color, 200 dpi, A4 Portrait)

Note: Results may vary depending upon your scanning application, computer processor and system memory
Scanning Area
(W x L)
Max: 216 x 5080 mm (8.5” x 200”)
Min: 13.2 x 13.2 mm (0.52” x 0.52”)
Acceptable Paper Sizes (W x L) Max: 244 x 5080 mm (9.6” x 200”)
Min: 50.8 x 50.8 mm (2” x 2”)
Acceptable Paper Weight (Thickness) 40 to 220 g/㎡ (10 to 58 Lbs)
Action Button 4 Buttons: Up, Down, Scan, Standby
9 function keys are all customizable.
Power Supply 24 Vdc/ 1.25 A
Interface USB 2.0 (with cable)
Net Weight 2.7 Kgs (5.95 Lbs)
Dimensions
(W x D x H)
318.7 x 230.7 x 228.3 mm (12.55" x 9.08" x 8.99")
Protocol Compatible with ISIS & TWAIN
OS Windows 2000 / XP / Vista / 7 / 8 / 10
Hardware Requirements Pentium IV 2.0 GHz processor (Pentium IV 3.0 GHz processor recommended)
CD-ROM Driver
One available USB Port (USB 2.0 recommended)
1GB RAM or higher recommended
800 MB free HDD space (1 GB or larger recommended)
