High Speed Duplex Document Scanner


- Duplex document scanning.
- Color, Resoltion 600 Dpi.
- 40 ppm/ 80 ipm
- Support longer paper up to 50 inches
- Ultrasonic function, protects double feeding during document scanning.
- Able to scan business card, ID card, credit card, Cheque, document up to A4.
- User-friendly
- Suitable for Government department, Academy, Factory, Business Office, etc.


Features


- Duplex document scanning.
- Color, 600 Dpi
- 40 ppm, 80 ipm
- The Ultrasonic function, detects double feeding of original documents during scanning.
- Support longer paper up to 50 inches.

- Auto crop, Auto size scanning, Auto deskew, Remove blank page, Image edge fill etc.
- Tray capacity 100 sheets.
- Able to scan A4, business card, credit card, plastic card, ID card.
- With one touch button, any documents will be convert to image files such as JPEG, BMP, PNG, TIFF, Multi-TIFF, PDF, Searchable PDF, scan to email, printing and OCR in order to save as Word or Excel.
- Able to use with WAC OMR.

Software Bundled

Hotcard BizCard Finder
BizCard Finder , provides BCR Technology and Photo /Document database for information management. Through BizCard Finder, you can quickly and easily convert the vital contact information on business cards into a convenient, searchable, digital database that can be easily synchronized between PC, NoteBook, and PDA

ABBYY FineReader Sprint
Powerful document management software for OCR, PDF creation, or format conversion to Microsoft Word, Excel, Text, Html, Searchable PDF. Support Thai and other 170 languages.

DI Capture
Image capture and management software featured with indexed archives. It also makes it easy to import, export, edit, and organize documents and images in an efficient way.

Doc Action
Button utility is designed to specify your personalized scanning configuration settings which make documents scanning easily.

Specification
Image Sensor CCD Sensor x 2
Light Source LED
Optical Resolution 600 dpi
Hardware Resolution 600 x 600 dpi
Scan mode Color: Input 48-bit,Output 24-bit
Grayscale: Input 16-bit,Output 8-bit
Black & White: 1-bit
ADF Capacity 1. 100 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs)
2. 30 sheets (Business Cards)
3. Plastic Card, Max. thickness under 1.2 mm.

Note: Maximum ADF capacity varies, depending upon paper weight.
Scanning Speed
( ADF ) .
40 ppm/ 80 ipm (Color mode, 200 dpi, A4 Portrait)
40 ppm/ 80 ipm (Grayscale mode, 300 dpi, A4 Portrait)
40 ppm/ 80 ipm (B&W mode, 300 dpi, A4 Portrait)

Note: Results may vary depending upon your scanning application, computer processor and system memory
Scanning Area
(W x L)
Max. 216 x 1270 mm (8.5” x 50”)
Min. 13.2 x 13.2 mm (0.52” x 0.52”)
Acceptable Paper Sizes (W x L) Max. 244 x 1300 mm (9.6” x 51”)
Min. 50.8 x 50.8 mm (2” x 2”)
Acceptable Paper Weight (Thickness) 40 to 220 g/㎡ (10 to 58 Lbs)
Action Button 4 Buttons: Up, Down, Scan, Standby
9 function keys are all customizable.
Power Supply 24 Vdc/ 1.25 A
Interface USB 2.0
Net Weight 2.7 Kgs (5.95 Lbs)
Dimensions
(W x D x H)
318.7 x 230.7 x 228.3 mm (12.55" x 9.08" x 8.99")
Protocol Compatible with ISIS & TWAIN
OS Windows 2000 / XP / Vista / 7 / 8
Hardware Requirements Pentium IV 2.0 GHz processor (Pentium IV 3.0 GHz processor recommended)
CD-ROM Driver
One available USB Port (USB 2.0 recommended)
1GB RAM or higher recommended
800 MB free HDD space (1 GB or larger recommended)
