Large size scanning Large format scanning of A3 size document (304.8 x 431.8 mm / 12” x 17”). | |
Fast scanning speed Fast scanning speed of 13 seconds for an A3 size color document at 300 dpi. | |
One-touch buttons design Seven one-touch buttons for performing pre-set functions; enable the user to accomplish tasks like scan, file, copy, OCR, PDF conversion, and email quickly. | |
Software Bundled | |
ABBYY FineReader |
Powerful document management software for OCR, PDF creation, or format conversion to Microsoft Word, Excel, Text, Html, Searchable PDF. Support Thai and other 183 languages. |
Plustek DocAction |
DocAction provides a personalized operation system; you can easily set up your scanning way and use to have a simple processing way and time-save making your work smart and quick. |
Page Manager |
The Perfect Solution for Managing and Sharing Documents! It is easy to scan, share, and organize their images and documents, while also helping them not only convert piles of papers into organized, digitized files, but also view, edit, send, and back up files in many formats. |
Specification | |
Scanning Type | CCD |
Optical Resolution | 1600 dpi |
Scan Modes | Color : Input 48-bit; Output 24-bit Grayscale : Input 16-bit; Output 8-bit Black & White : 1-bit |
Color Depth | Input 48-bit; Output 24-bit |
Scan Speed | 13 sec (Color/ Grayscale/ B&W mode, 300dpi, A3) |
Scanning Area (W x L) | Max. 304.8 mm x 431.8 mm (12" x 17"), A3 |
Action Button | Scan, OCR, Copy, File, Email, Custom1, Custom2 |
Power Supply | 24 Vdc/ 2.08 A |
Power Consumption | < 36 W (operation), < 8 W (idle) |
Interface | USB 2.0 |
Net Weight | 7.5 Kgs (16.52 Lbs) |
Dimension (WXDXH) | 623 x 400 x 133 mm (24.53” x 15.75” x 5.24”) |
Protocol | TWAIN compliant |
OS | Windows XP / Vista / 7 / 8 Intel-based Mac with OS X (v10.7 - v10.10) |
Hardware Requirements | PentiumR IV 2.0 GHz processor CD-ROM Driver One available USB 2.0 Port 512 MB RAM (1GB or higher recommended) 800 MB free HDD space (1 GB or larger recommended) |
