OpticPro A360L
High Speed A3 Scanner

Plustek OpticPro A360 is a USB 2.0 device that can scan an A3 size document with high quality and ultra scanning speed, A3 size in 2.4 seconds (colour at 300 dpi). It features advanced networking capabilities, rich functionality and comes bundled with valuable yet easy-to-use document management software.

• A3 size Large format scanner (12” x 17”).
2.4 second high speed scan at 300dpi color mode.
• Seven One-Touch button design for customization.
• High resolution 600 dpi.

Features

• A3 Flatbed scanner(12” x 17”)
• High speed scanning 2.48 seconds/page.
• User-Friendly.
• Bundled with simple-to-use image processing and document management tools, fast and secure PDF conversion, image organizer with thumbnail viewer, and accurate OCR software.

Software Bundled
ABBYY FineReader
Powerful document management software for OCR, PDF creation, or format conversion to Microsoft Word, Excel, Text, Html, Searchable PDF. Support Thai and other 183 languages.
Plustek DocAction
DocAction provides a personalized operation system; you can easily set up your scanning way and use to have a simple processing way and time-save making your work smart and quick.
Page Manager
The Perfect Solution for Managing and Sharing Documents! It is easy to scan, share, and organize their images and documents, while also helping them not only convert piles of papers into organized, digitized files, but also view, edit, send, and back up files in many formats.

Specification
Scanning Type CCD
Optical Resolution 600 dpi
Scan Modes Color : Input 48-bit; Output 24-bit
Grayscale : Input 16-bit; Output 8-bit
Black & White : 1-bit
Color Depth Input 48-bit; Output 24-bit
Scan Speed 2.48 sec (Color mode, 300dpi, A3)
1.65 sec (Grayscale/ B&W mode, 300dpi, A3)
Scanning Area (W x L) Max. 304.8 mm x 431.8 mm (12" x 17"), A3
Action Button Scan, OCR, Copy, File, Email, Custom1, Custom2
Power Supply 24 Vdc/ 2.08 A
Power Consumption < 36 W (operation), < 8 W (idle)
Interface USB 2.0
Net Weight 7.7 Kgs (16.96 Lbs)
Dimension (WXDXH) 623 x 400 x 133 mm./ 24.53” x 15.75” x 5.24”
Protocol TWAIN compliant
OS Windows 2000, XP, Vista, 7, 8, 10
Hardware Requirements PentiumR IV 2.0 GHz processor
CD-ROM Driver
One available USB 2.0 Port
512 MB RAM (1GB or higher recommended)
800 MB free HDD space (1 GB or larger recommended)
