Technical parameters
Interface : USB HID KEYBOARD/USB VCP
Voltage requirement : 5V DC±10%
Current consumption : 270mA Max，7mA Min

Optical Characteristics
Photo sensor : CMOS array sensor Sensor
Resolution : 640X480 pixels
Light source : Super-bright white LED*2
Aim light source : Green LED bar

Performance Characteristics
Scan Rate : Up to 100fps
Decode angle : Pitch angle：±65° Skew angle：±65° Tilt angle：360°
Min resolution : 1D:4mil(0.1mm)
Min.PCS value : 25% minimum reflective difference
curvature R≥15 mm (EAN8)，R≥20 mm (EAN13) （resolution=0.26mm，PCS=0.9）
Field of View : 38° (H) x 28.9° (V)

Identification
(1D): JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN-ISMN, Matrix 2of5, MSI/ Plessey, S-Code, Telepen, Tri-Optic, UK/ Plessey POSTAL CODE: Chinese Post, Intelligent Mail Barcode, Korean Postal Authority code, POSTNET

2D CODE: Aztec Code, Aztec Runes, Chinese Sensible code, Codablock F, Composite codes, Data Matrix (ECC200), Passport MRZ (OCR-B), Maxi Code (mode 2~5), MicroPDF417, Micro QR Code, PDF417, QR code

Performance Characteristics
Dimensions : 108mm H x71 mm W x185 mm D
Weight : 226g
Case : material PC white
Shock drop test : 1.8m drop onto concrete surface

Environment Characteristics
Temp : 0° C to 40° C ( -4°F - 140°F )(operation) ， -40° C to 70° C (-40°F -185°F)storage)
Humidity : 5%-95% (无凝结)
Ambient Light : Indoor illumination1600 Lux Sun illumination 86000 Lux

Regulatory
Electrical Safety : UL60950-1 2nd ed, CSA C22.2 No. 60950-1 2nd ed, EN60950-1/IEC60950-1 2nd ed.
LED Safety : IEC/EN60825-1:2001, IEC/EN62471:2006
EMI/RFI : FCC Part 15 Class B, ICES-003 Class B, EN55022 Class B, EN55024
Environmental : Compliant with RoHS directive 2002/95/EEC
Accessories : Cable (USB、RS232), Quick user manual, DC adapter (RS232 option)
