คุณสมบัติ

LCD Display

• - Screen size 21.5 in.
• - Native resolution 1920 x 1080 (16:9)
• - Backlight IPS LED
• - Active area size 476.64 x 268.11 mm.
• - Contrast ratio 1000 : 1 Brightness 250 cd/m2
• - Response time 14 ms Viewing angle 89O / 89O (H) / 89O / 89O (V) (Typical) (CR≥10)
• - Gamut 72% (NTSC)
• - Display color 16.7 M (8 bit)

Pad and Pen

• - Reading technology Battey-free electromagnetic resonance
• - Coordinate resolution 5080 LPI
• - Pressure levels 8192
• - Coordinate accuracy ±0.5 mm. (Center) , ±3 mm. (Corner)
• - Reading height 10 mm.
• - Report rate 233 point per second

General

• - Power supply 100-240V AC, 50/60 Hz
• - Communication interface USB type-C
• - Button Power switchx1, touch switch x1
• - Net weight 4.5 kg
• - Dimension 517 x 323 x 37 mm.
• - Main body color White or black
• - OS Support Win 7 or later, MAC OS 10.11 or later
• - Power consumption 2.4W
• - Standby consumption 0.3W
